Product Data Sheet
Engraved Cast Acrylic Equipment Nameplates
Commercial-grade engraved equipment tags constructed from two-tone acrylic and available with 3M 468MP adhesive backing, mounting holes, or no mounting.
Downloads
Submittals, SDS, adhesive data, and material specifications.
Use these documents for contractor submittals, project closeout, material review, and commercial equipment tag approvals.
Lightline Equipment Tags Submittal Package
Summary package including product overview, product data sheet, material data, adhesive data, SDS, installation notes, and warranty information.
Download → PDFTroLase Textures / Ultra Technical Datasheet
Technical data for the acrylic material, including thicknesses, UV resistance, engraving depth, properties, compliance, and storage guidance.
Download → PDFTroLase SDS
Safety Data Sheet for TroLase materials supplied as a service document for safe handling, storage, and processing review.
Download → PDF3M 468MP Adhesive Transfer Tape TDS
Technical data for 3M high-performance acrylic adhesive, including adhesion, temperature resistance, environmental resistance, and application guidance.
Download →Material
Trotec TroLase two-tone acrylic / impact modified PMMA, available in multiple colors and thicknesses.
Adhesive
3M 468MP high-performance acrylic adhesive backing available for clean installation on suitable surfaces.
Common Uses
Mechanical equipment, switch boxes, panels, valve installations, project identification, and closeout tag packages.
Installation
Clean and dry the surface, peel liner, apply firm even pressure, and use a roller where practical for maximum bond.
| Use | Switch boxes, mechanical equipment, valve installations, panels, and commercial identification. |
|---|---|
| Material | Rigid cast acrylic material that is electrically non-conductive. |
| Thickness | 1/16 in. (1.5875 mm), with additional material options by request. |
| Finish | Gloss / matte finish options. |
| Colors | White letters on black, black letters on yellow, white letters on red, black letters on white, and custom color requests. |
| Mounting | Adhesive backing, two holes, four holes for applicable sizes, or no mounting. |
| Service Temperature | -40°F to 176°F (-40°C to 80°C) |
| Typical Sizes | 2-1/2”W x 3/4”H, 2-1/2”W x 1”H, 3”W x 1”H, 4”W x 1-1/2”H, 4”W x 2”H, 5”W x 3”H, 6”W x 4”H, and custom sizes. |
